TP-Link MC110CS 10/100Mbps Single-mode Media Converter

Description

The TP-Link MC110CS converts a 10/100 Mbps Ethernet connection to single-mode fiber, extending network reach by up to 20 km at a 1310 nm wavelength. It suits offices, commercial, and industrial environments where fiber cabling must be integrated into an existing Ethernet infrastructure. Ports include one 100M SC/UPC fiber port and one 100M RJ45 port with Auto MDI/MDIX.

Compliant with IEEE 802.3, 802.3u, and 802.3x, the unit supports auto-negotiation of half/full duplex and flow control in both modes. Maximum power consumption is 2.4 W. Operating temperature range is 0–40°C, and the device carries FCC, CE, and RoHS certifications.

• Fiber reach: Up to 20 km (single-mode, 1310 nm)
• Ports: 1 × 100M SC/UPC fiber, 1 × 100M RJ45 (Auto MDI/MDIX)
• Standards: IEEE 802.3, 802.3u, 802.3x
• Power consumption: Max 2.4 W
• Certifications: FCC, CE, RoHS
